Highlights

1.Each group of main cylinders are equipped with a parachute valve to
ensure safety. Nylon slide pads, long life-used, Maintenance free
for its lifetime Two installation ways make it easy to open car doors.
2.Environment-friendly and low noise design. Equipped with 600mm
column extension frame and 1200mm column extension frame.
Two different column extensions for different space options.

3.The column adopts an 8-fold bending structure and built-in
reinforcement to maximize the column strength. Unique electro
locking system is designed without defect.
4.Base plate thickness is 20mm, Support arm thickness is 6/8mm.
Parachute valve inside the cylinder ensures user safety. The door
anti-collision rubber protection is put on the carriage and support
arm to facilitate the entry and exit from the vehicle.The length of carriage
is 1.8m.

5.Vulcanized rubber pad has long life.
Each lift passes the test of 115% dynamic load and 150% static load,
safe and reliable.
