Description
Inheriting the streamlined appearance of CB68, measuring the two
value tire parameters automatically, switching “STD” and “ASL2”
balance modes intelligently without any manual operation to
choose the model of balance, pedal brake to make sure the higher
accuracy of positioning, equipped with lighting system, cannot
operate during darkness? Tell you what, nothing is impossible.

Highlights
The machine has Italian software, user-friendly.
Automatic acquisition of diameter, distance. The machine has 5 ALU
balancing programs and 2 ALU smart balancing programs.
The machine also has optimization function and weight split function.
The diameter of balancing shaft is 40mm so it can work with standard
accessories.
The machine has motorcycle balancing programs, it can balance
various motorcycle wheels.
The machines can be optionally equipped with motorcycle adaptor.
LED illuminator for easy and clear operation.
The calibration is easy to proceed, the machine can quickly get back its
precision.
LED display
The machine has pedal brake to help user when applying the
weight on the wheel.
The machine will go into stand-by when it is not being used for a
certain time.
Intelligent toggle of STD and ALS2 balance modes.(SMART ARM)

Technical data
Rim diameter                                                                 1” - 28” inch
Max wheel weight                                                                    70 kg
Max wheel diameter                                                           1118 mm
Rim width                                                                    1,5” - 20” inch
Precision                                                                                     ±1g
Motor Power                                                                              90W
Power supply                                                              100/230V 1ph
Rotation per minute                                                              140rpm
Balancing time                                                                              7s
Second time mounting test                                                         ≤5g
Machine dimensions                                      1550x1160x1240 mm
Packing dimension                                             990x760x1150 mm
Net weight                                                                              128 kg
Gross weight                                                                          166 kg
Loading in 40 Ft. container                                                    72 sets
