Description
Safety being first is our designing concept! The protection of tire and
rim , is not only a modern interpretation of the safe concept, but also
much easier and more practical. Redefine the safe pursuit of tire services
through modern design.

Highlights
Standardly equipped with 80mm diameter small cylinder in working
table , the clamping force increases 58kg than the 75mm.The rim can
be held firmly and assure no rim damage .
Standardly equipped with spacer, which meets the CE requirement and
protects the operator during mounting and demounting.
The Italian-design pedal assembly has ergonomic structure, sealing
performance is stable, appearance updated, unified brand image.
Double-bending column is made of steel plate with 5mm thickness,
high robustness.
Adopted special parkerising technique cylinder, avoid the cylinder rust ,
increasing service life.
Adopted diameter 55mm horizontal shaft , the lengthened hex bar
sleeve makes the machine more intensive.
Optional equipped with AL390 assist arm which adopted tire pressing
block for the rim centering, easy and convenient operate. Enhancing
the efficiency in mounting and demounting. Optional equipped tire lifter
SR69 , labor saving.
